Section |
Dimensions |
sectional |
Mass |
Moment of inertia |
Modulus of Section |
||||
Width |
Height |
Thickness |
Per pile |
Wall |
|||||
B |
H |
t |
s |
|
|
|
|
|
|
mm |
mm |
mm |
cm2/m |
kg/m |
kg/m2 |
cm4/m |
cm3/m |
||
HRSP-U-530 |
400 |
85 |
8.0 |
- |
113.0 |
35.5 |
88.7 |
4500 |
530 |
HRSP-U-870 |
400 |
100 |
10.5 |
- |
153.0 |
48.0 |
120.1 |
8740 |
870 |
HRSP-U-1340 |
400 |
125 |
13.0 |
- |
191.0 |
60.0 |
149.9 |
16800 |
1340 |
HRSP-U-1560 |
400 |
145 |
12.7 |
9.4 |
197.3 |
62.0 |
155.0 |
22580 |
1560 |
HRSP-U-1785 |
400 |
146 |
15.0 |
9.7 |
220.8 |
69.3 |
173.3 |
26090 |
1785 |
HRSP-U-1520 |
400 |
150 |
13.1 |
- |
186.0 |
58.4 |
146.0 |
22510 |
1520 |
HRSP-U-2270 |
400 |
170 |
15.5 |
- |
242.5 |
76.1 |
190.4 |
38600 |
2270 |
HRSP-U-3150 |
500 |
200 |
24.3 |
- |
267.6 |
105.0 |
210.1 |
63000 |
3150 |
HRSP-U-2000 |
500 |
210 |
11.5 |
- |
197.4 |
77.5 |
155.0 |
42000 |
2.000 |
HRSP-U-2500 |
500 |
210 |
15.6 |
- |
222.0 |
87.5 |
175.0 |
52500 |
2500 |
HRSP-U-3040 |
500 |
210 |
20.0 |
- |
262.0 |
103.0 |
206.0 |
63840 |
3040 |
HRSP-U-3820 |
500 |
225 |
27.6 |
- |
306.0 |
120.1 |
240.2 |
86000 |
3820 |
Section |
Dimensions |
sectional |
Mass |
Moment of inertia |
Modulus of Section |
||||
Width |
Height |
Thickness |
Per pile |
Wall |
|||||
w |
h |
t |
s |
|
|
|
|
|
|
mm |
mm |
mm |
cm2/m |
kg/m |
kg/m2 |
cm4/m |
cm3/m |
||
HRSP-U-1000 |
600 |
130 |
10.3 |
- |
131.2 |
61.8 |
103.0 |
13000 |
1000 |
HRSP-U-735 |
600 |
155 |
7.5 |
- |
99.6 |
46.9 |
78.2 |
11437 |
735 |
HRSP-U-835 |
600 |
155 |
8.2 |
- |
115.0 |
54.1 |
90.2 |
12960 |
835 |
HRSP-U-625 |
600 |
154.5 |
6.0 |
6.0 |
89.0 |
41.9 |
69.9 |
9670 |
625 |
HRSP-U-675 |
600 |
155 |
6.5 |
6.4 |
93.7 |
44.1 |
73.5 |
10450 |
675 |
HRSP-U-1165 |
600 |
155 |
9.7 |
- |
138.1 |
65.0 |
108.4 |
18100 |
1165 |
HRSP-U-740 |
600 |
155.5 |
7.2 |
6.9 |
100.3 |
46.3 |
77.1 |
11540 |
740 |
HRSP-U-745 |
600 |
156 |
7.3 |
6.9 |
100.7 |
47.4 |
79.1 |
11620 |
745 |
HRSP-U-770 |
600 |
156 |
7.5 |
7.1 |
103.1 |
48.5 |
80.9 |
12010 |
770 |
HRSP-U-820 |
600 |
156.5 |
8.0 |
7.5 |
107.8 |
50.8 |
84.6 |
12800 |
820 |
HRSP-U-995 |
600 |
158 |
9.0 |
6.8 |
118.5 |
55.8 |
93.0 |
15700 |
995 |
HRSP-U-1095 |
600 |
159 |
10.0 |
7.4 |
127.8 |
60.2 |
100.3 |
17450 |
1095 |
HRSP-U-1200 |
600 |
160 |
11.0 |
8.0 |
137.2 |
64.6 |
107.7 |
19220 |
1200 |
HRSP-U-1200 |
600 |
180 |
9.8 |
9.0 |
140.0 |
66.1 |
110.1 |
21600 |
1200 |
HRSP-U-1255 |
600 |
180 |
10.0 |
- |
147.8 |
69.6 |
116.0 |
22580 |
1255 |
HRSP-U-1260 |
600 |
180 |
10.0 |
10.0 |
151.0 |
71.0 |
118.3 |
22660 |
1260 |
HRSP-U-1800 |
600 |
180 |
13.4 |
- |
173.2 |
81.6 |
136.0 |
32400 |
1800 |
HRSP-U-1600 |
600 |
190 |
10 |
- |
156.1 |
73.5 |
122.6 |
30400 |
1600 |
HRSP-U-1270 |
600 |
209 |
9.0 |
7.4 |
127.2 |
59.9 |
99.8 |
26590 |
1270 |
HRSP-U-1400 |
600 |
210 |
10.0 |
8.0 |
136.5 |
64.3 |
107.1 |
29410 |
1400 |
HRSP-U-2020 |
600 |
210 |
12.5 |
- |
177.5 |
83.6 |
139.3 |
42426 |
2020 |
HRSP-U-2700 |
600 |
210 |
18.0 |
- |
225.5 |
106.2 |
177.0 |
56700 |
2700 |
HRSP-U-1530 |
600 |
211 |
11.0 |
8.6 |
145.9 |
68.7 |
114.5 |
32260 |
1530 |
HRSP-U-1670 |
600 |
215 |
10.2 |
8.4 |
154.2 |
72.6 |
121.0 |
35950 |
1670 |
HRSP-U-1800 |
600 |
215 |
11.2 |
9.0 |
163.3 |
76.9 |
128.2 |
38650 |
1800 |
HRSP-U-1920 |
600 |
215 |
12.2 |
9.5 |
172.3 |
81.1 |
135.2 |
41320 |
1920 |
HRSP-U-2410 |
600 |
217.5 |
13.9 |
- |
200.6 |
92.2 |
153.7 |
52420 |
2410 |
HRSP-U-2060 |
600 |
225 |
11.1 |
9.0 |
173.9 |
81.9 |
136.5 |
46380 |
2060 |
HRSP-U-2200 |
600 |
225 |
12.1 |
9.5 |
182.9 |
86.1 |
143.6 |
49460 |
2200 |
Section |
Dimensions |
sectional |
Mass |
Moment of inertia |
Modulus of Section |
||||
Width |
Height |
Thickness |
Per pile |
Wall |
|||||
w |
h |
t |
s |
|
|
|
|
|
|
mm |
mm |
mm |
cm2/m |
kg/m |
kg/m2 |
cm4/m |
cm3/m |
||
HRSP-U-2335 |
600 |
225 |
13.1 |
10.0 |
192.0 |
90.4 |
150.7 |
52510 |
2335 |
HRSP-U-2680 |
600 |
226 |
14.2 |
9.7 |
206.8 |
97.4 |
162.3 |
60580 |
2680 |
HRSP-U-2840 |
600 |
227 |
15.2 |
10.1 |
216.1 |
101.8 |
169.6 |
64460 |
2840 |
HRSP-U-3065 |
600 |
226 |
18.5 |
10.6 |
233.3 |
109.9 |
183.2 |
69210 |
3065 |
HRSP-U-3200 |
600 |
226 |
19.0 |
- |
241.7 |
114.0 |
190.0 |
72320 |
3200 |
HRSP-U-3200 |
600 |
226 |
19.5 |
11.0 |
242.3 |
114.1 |
190.2 |
72320 |
3200 |
HRSP-U-3340 |
600 |
226 |
20.5 |
11.4 |
251.3 |
118.4 |
197.3 |
75410 |
3340 |
HRSP-U-2700 |
600 |
228 |
15.8 |
- |
206.1 |
97.1 |
161.8 |
61560 |
2700 |
HRSP-U-3000 |
600 |
228 |
16.2 |
10.5 |
225.6 |
106.2 |
177.1 |
68380 |
3000 |
HRSP-U-1150 |
700 |
200 |
9.0 |
- |
120.0 |
65.1 |
93.0 |
23000 |
1150 |
HRSP-U-1340 |
700 |
200 |
10.0 |
- |
137.6 |
75.6 |
108.0 |
26800 |
1340 |
HRSP-U-1535 |
700 |
220 |
9.7 |
- |
140.9 |
77.4 |
110.6 |
33770 |
1535 |
HRSP-U-1405 |
750 |
204 |
10.0 |
8.3 |
132.3 |
77.9 |
103.8 |
28680 |
1405 |
HRSP-U-1600 |
750 |
205.5 |
11.5 |
9.3 |
146.5 |
86.3 |
115.0 |
32850 |
1600 |
HRSP-U-1780 |
750 |
220.5 |
10.5 |
9.1 |
150.3 |
88.5 |
118.0 |
39300 |
1780 |
HRSP-U-2000 |
750 |
222 |
12.0 |
10.0 |
164.6 |
96.9 |
129.2 |
44440 |
2000 |
HRSP-U-2270 |
750 |
223.5 |
13.0 |
9.5 |
173.4 |
102.1 |
136.1 |
50700 |
2270 |
HRSP-U-2500 |
750 |
225 |
14.5 |
10.2 |
187.5 |
110.4 |
147.2 |
56240 |
2500 |
HRSP-U Palancola Le osservazioni sul campo a lungo termine indicano che Palancole in Acciaio offre una lunga durata di servizio se correttamente progettate. Palancole in Acciaio Le installazioni permanenti dovrebbero consentire la successiva installazione della protezione catodica in caso di corrosione eccessiva.
